Features:
12 channel A4 size ECG printing
7 inch colour TFT display with
touch screen
Configurable printing formats
Latest interpretation software with
auto analysis
In-built thermal printer
Dedicated software to download
ECG in PDF format
Measuring Parameters:-
Display Type 7" Color TFT
Frequency Response
Filters - 0.05 to 125Hz
Low pass, high pass, AC filter,
notch filter, artifact filter
Sweep Speed 12.5/25/50 mm/sec
Sensitivity 5/10/15/20 mm/mV
Patient Storage Data - Upto 100 patients
Printer Type Thermal digital array printer
Paper Width A4 size (210 mm )
Defib Protection Yes
Recording Time 10 Sec.
Alphanumeric Keyboard Virtual
USB Interface USB, PDF generation
Indication No cable, paper over, printer
head open, low battery
ECG Print Style
Measuring Parameters
Mode of Operation Auto, Manual
Long Lead Print Yes
Accessories
10 lead patient cable 1 No.
Paper Roll 1 No.
Power Cord 1 No.
Power Consumption 65 Watt
Electrical
Power Supply 100-240 VAC, 50Hz
Battery Type - Inbuilt rechargeable battery
Battery Rating - 11.1 V, 5200 mAh, Li-ion Battery
Recharging Time - 4 Hours Max.
Operating Time - >30 ECG’s
Power saving mode - >3 Hours on standby Enabled
Physical Characteristics
Weight - 2.730 Kg
Dimensions - 308 (L) x 240 (B) x 80(H) mm
Defib Protection Yes
Patient Compatibility Adult, Pediatric & Neonatal
